Enerwatt EWC12-148 12 Volt Smart Charger Automatic 1/4/8 AMP

Description

ENERWATT EWC12-148 12V 100% Automatic Smart Charger

Technical Specifications:

Model Number: EWC12-148

Type: Smart

Input Voltage Range: 100 - 120Vac

Input Frequency: 50/60Hz

Output: 8A @ 12V

Start Voltage: 2V

Charge Voltage: GEL - 14.1V / AGM & WET - 14.4V / Pure Lead - 14,7V

Equalizing Voltage: AGM & WET - 15.5V / Pure Lead - 16.2V

Float Voltage: 13.2V

Rejuvenation Voltage: 16.0V

Rejuvenation Current: 0.5 - 1.0A

Size (L * W * H) in mm: 217 * 104 * 58

Weight: 1.1kg

Approvals: CE, UL/cUL, FCC, AS, NZS, DOE

BATTERY TYPES & CAPACITY

• Suits all Lead Acid Type Batteries. (GEL, WET, AGM, Pure Lead)

• Adjustable charge rate: 12V volt battery



	Deep Cycle (AH)	Automotive (CCA)	Marine (MCA)	Time (Hours)
1Amp	7-20	40-120	55-165	7-24
4Amp	30-80	180-480	250-650	7-24
8Amp	60-160	360-1000	500-1300	7-24

ENVIRONMENTAL CHARACTERISTICS

• Operating Temperature: 0 to 40° C

• Storage Temperature: -10 to 80°C

• Operating Humidity Range: 90% RH Max

• Cooling: natural cooling

Features:

- LED display of the state of charge and selected options.

- Protection against reversed polarity, overload and short-circuit.

- 2 types of connectors included: clamps and eyelets.

- Corrosion resistant.

The EWC12-148 fully automatic high frequency charger features a  microprocessor which charges conventional 12V batteries (car, motorcycle), deep cycle (RV, boat), gel, AGM (electric bike) and pure lead batteries.

It has an easy to set interface with a selection of three charge levels: 1, 4 and 8 amperes and two optional charge modes to prolong the life of your battery: equalizing and conditioning.

A Rapid Charger That Prolongs The Life of Your Battery

The EWC12-148 is a pulse charger, it uses fast variations of high voltage (pulses), higher than the average constant load chargers.

Result:  a faster charge, perfect every time, causes less evaporation than regular chargers, prolongs the life of your batteries and needs less maintenance.

Moreover, the conditioning mode reverses the accumulation of sulphates on the plates of the battery, which may give more power to an old battery.

For acid batteries, the equalization mode is used to level each cell of the battery for a balanced operation which optimizes performance.

Perfect For Charging In Storage

Perfect for the storage of batteries, it itself detects if batteries need charging or not. 100% safe and hassle free.

A Complete Intelligent Charger

Practical interchangeable cables for a permanent installation on a motorcycle or a deep cycle battery or for an easy connection when maintaining or storing batteries.

Click Here To View The Owners Manual For Full Technical Details
